IMPACT CRUSHING & SCREENING

MI350RTE Tracked Mobile Impact Crushing & Screening Plant

MI350RTE

Max Capacity

250-500 t/h

Complete Machine Power

352 kw

Maximum Output Size

0-0 mm

PRODUCT OVERVIEW

The MIDAS MI-RTE Series tracked mobile crushing and screening plant integrates crushing and screening onto a single chassis. Featuring hybrid (diesel-electric) power and PLC one-button smart start, it performs both primary and secondary crushing of medium-soft rock and construction waste. This versatile unit offers broad application, high intelligence, and simplified operation.

Application Scenarios:

Primary and secondary crushing of medium-hard materials
Mining (ore/coal)
Concrete batching plants
Dry-mix mortar/flue gas desulfurization (FGD), silica sand, construction waste recycling, road and bridge construction

Model Code	Weight (T)	Power (KW)	Main Unit	Main Dimensions	Features
MI260RTE	68	322	PF1213	1200*1300	Double-layer screening, side discharge belt, Oil and electricity dual-purpose system 400kw
MI350RTE	74	352	PF1315	1300*1500	Double-layer screening, side discharge belt, Oil and electricity dual-purpose system 500kw
TX2IE	65	325.3	PF1213	1200*1300	Triple-layer screening, double side discharge belt, Oil and electricity dual-purpose system 400kw
TX3IE	88	376.7	PF1315	1300*1500	Pre-screening system, triple-layer screening, double side discharge belt, Oil and electricity dual-purpose system 500kw
