INCLINED SCREEN

MS3618 Tracked Mobile Inclined Screen

MS3618

Capacity

200-500 t/h

Complete Machine Power

68.5-108 kw

Maximum Output Size

0-0 mm

PRODUCT OVERVIEW

Equipped with vehicle-mounted automatic folding conveyor belts, Midas MS Series Tracked Mobile Screening Plant offers high processing capacity for precise material screening. Ideal for screening finished products from various sand, gravel, and construction waste after crushing. Features flexible site mobility, outstanding durability, and high reliability.

Application Scenarios:

Screening and processing of raw or coarse materials
Grading of sand, gravel, and river pebble materials
Classification of construction waste materials
Sorting of metallurgical and coal materials
Grading of building materials

Model Code	Weight (T)	Power (KW)	Main Unit	Main Dimensions	Features
MS3618	34	68.5	M3618	6000*1800
MS3618E	35	68.5	M3618	6000*1800	Oil and electricity dual-purpose system 120kw
MSF3618	39	83.5	M3618	6000*1800	Feeding system
MSF3618E	40	83.5	M3618	6000*1800	Feeding system, Oil and electricity dual-purpose system 150kw
MS3720	37	74.5	M3720	7000*2000
MS3720E	38	74.5	M3720	7000*2000	Oil and electricity dual-purpose system 120kw
MS5618	49	108	M5618	6000*1800
MS5618E	50	108	M5618	6000*1800	Oil and electricity dual-purpose system 150kw
